Sometimes nature needs a helping hand.

Vast underwater forests have gone missing from the Sydney coastline, with repercussions for local fish, ABALONE, CRAYFISH and coastal marine biodiversity.

We have a solution, but the ocean needs your help.

donate - Give an underwater tree

Thanks to Stephen Oliver and Shannon Ruddock for shooting this amazing video.

Photography courtesy of Justin Gilligan, John Turnbull (www.marineexplorer.org) & UNSW



THE PROBLEM

MISSING: 70 km stretch of
underwater forest!

 ‘Crayweed’ (Phyllospora comosa) once formed dense beds on shallow reefs all along the Sydney coastline, but sometime during the 1980s it all disappeared!

THE SOLUTION

SEAWEED SEX
And lots of it...

Crayweed can either be male or female and their sexually produced babies attach permanently to the reef, forming the basis of a new, self-sustaining population.



FOLLOW US ON INSTAGRAM

THE SCIENCE

Lost evidence and
new scientific solutions.

This loss of underwater forest went unnoticed and unreported in the scientific literature until 2008, when Coleman et al. published an article...



Seaweeds may not be the most glamorous of sea creatures, but they’re AMONG the most important, providing critical food and habitat that supports hundreds of species. Just like trees on the land, seaweeds form vast underwater forests that underpin coastal food webs, all while quietly capturing atmospheric carbon and producing precious oxygen.

Alarmingly, temperate seaweed forests are in decline, due to multiple human activities. This is bad news for anyone who enjoys eating seafood, diving or fishing, because if seaweed forests disappear, all the critters that depend on them will disappear too and we’ll have no crays or abalone to see, catch or eat.

‘Crayweed’ forms dense forests on shallow reefs all the way from Port Macquarie to Tasmania. Crayweed (scientific name Phyllospora comosa) used to also be very abundant along the Sydney coastline, but sometime during the 1980s it disappeared completely from the metropolitan area between Palm Beach and Cronulla. The high volumes of poorly treated sewage that were pumped directly onto Sydney’s beaches and bays before the 1990s  likely caused this decline. The problem is that although water quality in Sydney has improved dramatically since the establishment of deep ocean sewage outfalls, the crayweed forests have not returned.

Crayweed provides food and habitat to a huge diversity of fish and invertebrates, including economically important abalone and crayfish. Other species of seaweed do not play the same role in Sydney’s marine environment, so losing crayweed is bad news for our local marine biodiversity.

The aim of OPERATION CRAYWEED is to bring crayweed back to reefs where it
once flourished and to re-establish this essential habitat and food source for Sydney’s coastal marine biodiversity.








Scientists at OPERATION CRAYWEED have already developed a successful method to create crayweed forests on reefs where they were once dominant, by transplanting healthy, fertile adults from existing populations and attaching them to deforested rocks using BIODEGRADABLE mesh drilled into the bottom. There, they survive, they thrive and they start having sex – a lot of sex.

Crayweed can either be male or female and their sexually produced babies attach permanently to the reef, forming the basis of a new, self-sustaining population, which expands from the initially restored patch. We now find adult crayweed (offspring from the original crayweed restoration experiment) hundreds of metres from the original patch.

So by creating patches of transplanted crayweed onto a reef, we can, in the long term, restore forests of this essential species in an entire site.

The idea here, of course, is that by restorating crayweed we’re also restoring its associated community, and thereby increasing the chances of finding crayfish, abalone and a huge diversity of other fish and invertebrates at restored sites, which is good news for snorkelers, fishers, beach goers and seafood lovers.

We are very grateful to the NSW Environmental Trust and the Recreational Fishing Trust , who funded the research that led to the development of these restoration methods.






Crayweed (Phyllospora comosa) is a big brown species (in the group Fucales) that used to dominate the Sydney coastline. The loss of crayweed across 70 km of its range went unnoticed and unreported in the scientific literature until 2008, when our team (Coleman et al. 2008) published an article describing a conspicuous gap in the distribution of crayweed in south-eastern Australia, matching the extent of the Sydney metropolitan area.

Our research has shown that crayweed supports unique biodiversity, including commercially important species like lobster and abalone (Marzinelli et al. 2014), specific assemblages of epifauna (Marzinelli et al. 2015) and microbial communities (Campbell et al. 2015) that are not associated with other co-occurring species of macroalgae. It also contributes to detritus in soft sediment habitats (Bishop et al. 2010), which underpins food webs of key fish species including mulloway and bream.

The local disappearance of crayweed from the most urbanised stretch of coastline on the Australian continent was linked to the high volumes of poorly treated sewage that used to flow onto Sydney’s shores before the construction of deep ocean outfalls in the 1990s. These outfalls and improvements in wastewater treatment practises have vastly increased water quality around Sydney since the 1980s (Scanes & Philip, 1995) but despite this, crayweed has failed to recover.

In our initial pilot experiments, we tested the hypothesis that today’s water quality along Sydney’s coastline is suitable for the survival of crayweed transplants. We transplanted crayweed from extant populations to the north and south of Sydney, back onto Sydney reefs with suitable control treatments, and we found that the transplanted crayweed not only survived similarly well to those in natural populations, but they reproduced more and had more babies (Campbell et al. 2014). Moreover, by restoring crayweed we also restored unique creatures associated with it, which are key components of biodiversity (Marzinelli et al. 2015).

Thus, by restoring seaweed populations, we have the potential to enhance coastal biodiversity, improving the ecological and economical value of marine environments around Sydney.

Operation Crayweed is a flagship project from the Sydney Institute of Marine Science.

This research has been funded by the NSW Department of Primary Industries under the Environmental Trust and Recreational Fishing Trust grants, the Australian Research Council, the Sim-Lutton and Breen Initiatives and the John T Reid Foundation, as well as the Evolution & Ecology Research Centre, UNSW Sydney and a large number of individuals - please see full list of supporters here.





Crayweed Facts

For the more scientific amongst us!



  •  Crayweed = “Phyllospora comosa” = “Phyllospora” = “P. comosa”
  • Crayweed was once dominant on reefs in Sydney, but disappeared completely from the coastline adjacent to the metropolitan area during the late 1970s and early 1980s (Coleman et al. 2008).
  • Its disappearance coincided with high volumes of poorly treated sewage waste that was (until the late 1980s and early 1990s) released directly onto Sydney’s beaches and bays (Coleman et al. 2008).
  •  Water quality has improved dramatically since that time, due largely to the construction of deep water sewage outfalls (Scanes & Phillip 1995; Sydney Water Report 2007), but crayweed has failed to recover in Sydney (Coleman et al. 2008).
  • Crayweed supports a unique component of coastal biodiversity, which is not supported by any other extant seaweed species. Therefore, once it’s lost from an ecosystem, many other organisms and ecosystem services are also lost.
  • Crayweed supports much higher abundances of abalone (7-10 times) than other seaweed species in the region (e.g. Ecklonia radiata) or barrens habitat (Marzinelli et al. 2014).
  • Crayweed also contributes uniquely to detrital food webs (Bishop et al. 2010), which support recreationally and commercially important fish species, including Bream and Mulloway.
  • Crayweed has a specific diversity of microbes on its surface, compared to other seaweed species (Campbell et al. 2015).
  •  In our first attempt to restore this seaweed (initial experiment run between February 2011 – May 2011 and repeat experiment set-up in August 2011), survival rates of transplanted crayweed were similar to those in undisturbed, remnant populations (~70%; Campbell et al. 2014).
  • Rates of reproduction and the resulting numbers of babies (“recruits”) was very high – around 100/0.1 m2 (ten times higher), 6 and 12 months after transplantation (Campbell et al. 2014).
  • By late 2015, none of the originally transplanted, fertile adults remained (through natural loss and mortality.). However, many of the ‘babies’ produced by our transplants remain, firmly attached to the rock and have now become reproductive adults in their own right. We now find dozens of these new plants at our sites, tens or even  hundreds of metres from the originally restored patch, indicating that this method can successfully restore self-sustaining populations of crayweed at places where it was once dominant but has been missing for decades.

Photo John Turnbull

Photo John Turnbull

Photo John Turnbull

Photo John Turnbull

Photo John Turnbull

Photo John Turnbull

In June 2017, UNSW Sydney hosted the 21st Presidents Meeting & CEO Summit "The Future of the Pacific and its Societies".

This meeting brought together leaders from the Association of Pacific Rim Universities network to discuss issues affecting our region and to develop strategies that can have a meaningful impact on our region's future.

To mark the occasion, the Operation Crayweed team planted a new underwater crayweed forest in iconic Bondi Beach on behalf of all APRU delegates.



Underwater mats were drilled into the bare ocean floor in May 2017 and crayweed plants from nearby reefs were transplanted to the new site in north Bondi in June 2017.

North Bondi Drone Shot - Drilling 5.6.17 3.jpg

Prior to planting, a series of underwater surveys were done to characterise biodiversity, so that changes that result from reintroducing crayweed can be adequately quantified.

We hope this new APRU forest will play an important part in the improvement of the local underwater habitat around Bondi.

We will be monitoring crayweed survival and associated critters and watching out for craybies by the end of 2017– watch this space for news on how the forest evolves!

Check out this VIDEO to watch how this new APRU crayweed forest came into being. Filmed and edited by the talented John Turnbull, a.k.a. Marine Explorer.



UNDERWATER FOREST RESTORATION

- PhD OPPORTUNITIES -

We are seeking 3 highly motivated PhD students to join a coastal restoration research team in the Sydney region

This is an exciting opportunity to join an interdisciplinary team of researchers working on the following three coastal restoration projects:

Restoration Through Harvest: Linking urchin fisheries, communities and kelp forest restoration – funded by WWF’s Innovate to Regenerate program. Supervisors: Prof Adriana Vergés (UNSW) & Dr Ziggy Marzinelli (University of Sydney). Collaborators: John Keane (University of Tasmania), Aaron Eger (Kelp Forest Alliance).

Using plant-sediment-feedbacks to enhance effective seagrass restoration – funded by an Australian Research Council Linkage project. Supervisors: Dr Mariana Mayer-Pinto (UNSW), Prof Adriana Vergés (UNSW), Dr Ziggy Marzinelli (University of Sydney) & Paul Gribben (UNSW).

Project Restore – multi-species coastal restoration and rehabilitation focusing on seagrasses, kelp, fish pods and Living Seawalls; part of Seabirds to Seascapes a multi-institutional project funded by the NSW Environmental Trust. Supervisors: Prof Adriana Vergés (UNSW) & Dr Ziggy Marzinelli (University of Sydney). Collaborators: Dr Mariana Mayer-Pinto (UNSW), Katherine Dafforn (Macquarie University) & Melanie Bishop (Macquarie University) and David Booth (University of Technology Sydney).

THE APPLICANT: We are looking for someone with a keen interest in marine ecology and restoration and with a passion for solutions-focused research. SCUBA diving and advanced underwater fieldwork skills are needed. Boating experience and microbiology skills are advantageous, but not essential.

START DATE: From August/Sept 2023.

SCHOLARSHIPS FOR AUSTRALIAN STUDENTS: Students are expected to apply for an Australian Government Research Training Program Scholarship through either UNSW Sydney or the University of Sydney. UNSW Deadline for commencing in Sept 2023: 27th January 2023; USYD deadline for commencing in August 2023: 19 May 2023.

SCHOLARSHIPS FOR INTERNATIONAL STUDENTS: UNSW Sydney and the Australian Commonwealth Government offer highly competitive International Research Scholarships. UNSW deadline for international students commencing in Sept 2023: 27th January 2023; USYD deadline for international scholarships to commence August 2023: 12 December 2022.

Please note the following requirements to be competitive for an international scholarship:

- BSc equivalent to 1st Class Honours

- One or two publications in ISI scientific journals (at least one first-authored)

- Work experience in marine ecology



Interested students please email Prof Adriana Vergés (a.verges@unsw.edu.au), Dr Ziggy Marzinelli (e.marzinelli@sydney.edu.au) or Dr Mariana Mayer-Pinto (m.mayerpinto@unsw.edu.au) including a copy of your CV (in English) and your academic transcript.
